Precast Case Study
#Casestudy
Precast Outfall Structures
The design scope involved designing Precast Wingwalls, which were checked for sliding, overturning, and bearing capacity.
#Casestudy
Precast Wingwalls
The design scope involved designing Precast Tanks, including the Activated Sludge Basin Tank and Flash Aeration Tank, which were designed as propped cantilevers using STAAD Connect Software
#Casestudy
Precast Tank
The design scope involved designing Precast Tanks, including the Activated Sludge Basin Tank and Flash Aeration Tank, which were designed as propped cantilevers using STAAD Connect Software
#Casestudy
Precast Chambers
The design scope involved designing Precast chambers and cover slabs. The chamber walls, which have a large opening, were analyzed using STAAD software.
#Casestudy
Precast Culverts
The design scope involved designing Precast Culverts for Highway loading LM1, LM2, and LM3, in accordance with PD6694 and Eurocodes for Bridges.
#Casestudy
Bridge Wall
got appreciations for quality & quick responses/ RFI’s raised.
#Casestudy
Prison project
Trained new people for Allplan, Provided the good quality of output.
#Casestudy
Houses Residential Project
Trained new people for Allplan, Provided the good quality of output.
#Casestudy
Precast Residential Project
Create own fixture catalogue, worked on different structural elements in same project.
#Casestudy
Residential Building Project
Precast Detailing and Modelling for Sandwich Panels
#Casestudy
Residential Project
It was a cluster of 3 buildings we prepared a detailed engineering package.
#Casestudy
Staircase Residential Project
3D Models of various Precast elements – Staircase, Balconies, Landings & Hollowcore slabs
#Casestudy
Underground Motorway Project
Precast Detailing in 3D(TEKLA) for Exhaust & Supply Ventilation Building
#Casestudy
IFLY Projects
Preparation of 3D Model in TEKLA & Shop drawings for more than 36 units
#Casestudy
Commercial Building Project
Erection & Shop drawings, Shared model, 3D reinforcement model
#Casestudy
Commercial Centre Project
Redevelopment of an old commercial centre site to create a Company Headquarter Campus.
#Casestudy
Shopping Centre Project
The Project is a shopping centre, which has franchise across Australia. The project was about refurbishment to existing shopping centre.
#Casestudy
Commercial Bank Project
Provided 3D Modelling & Generation of Shop drawing and BBS from the Model
